TCK50 High Accuracy Medium Duty Slant Bed CNC Lathe Machine for Metal Turning Equipment
| MOQ: | 1 set |
| Price: | 16000USD |
| Standard Packaging: | Export standard wooden case or as customers' requirement |
| Delivery Period: | 15 days after getting the deposit. |
| Payment Method: | T/T |
| Supply Capacity: | 1000 sets/month |
Detail Information
Place of Origin
Shandong, China
Brand Name
Zaozhuang NO.1
Certification
CE,ISO
Model Number
TCK50
Document
Maximum Rotation Diameter On The Bed:
Φ550mm
Maximum Cutting Diameter:
Φ520mm
Processing Diameter Under The Turret:
Φ300mm
Maximum Cutting Length:
500mm
X-axis Travel:
260mm
Z-axis Travel:
600mm
Spindle Speed:
35-3000rpm
Product Description
TCK50 High Accuracy Medium Duty Slant Bed CNC Lathe Machine for Metal Turning Equipment
Featuring an inclined bed and monolithic structure for high rigidity and stability, the TCK50 is a high-performance precision CNC lathe capable of high-speed, high-precision turning operations. It utilizes a mainstream, user-friendly CNC system that facilitates the automatic machining of complex components. As such, it is widely adopted in industries like automotive, electronics, and medical devices for manufacturing precision parts, serving as an ideal solution to boost productivity and quality.
Standard Configuration:
1.Gsk CNC 988 TA
2.8-inch hydraulic Chuck
3.Hydraulic tailstock
4.Taiwan 8-station servo Tool turet
5.A2-6 spindle unit
6.Taiwan HIWIN screw/rail line
Product Specification:
Product Display:
